Aluminized Mylar Inner Window (Optistat CF/DN new style). A useful window for X-ray and gamma ray applications. The type of window material selected will be determined by the wavelenth and intensity of the radiation, the environmental temperature and whether or not beam polarisation is required.
Window Blank Inner Optistat -A range of replacement fittings and accessories are available to help you change the optical configuration of your cryostat.
Calcium Fluoride Middle Window (CF/DN old style/CCC). Calcium fluoride may be used in the near and mid IR. The type of window material selected will be determined by the wavelenth and intensity of the radiation, the environmental temperature and whether or not beam polarisation is required.
Microstat HR2 Top Plate With ZnSe 10mm Clear Access (ZOVC05HR2). Replacement top window plate for Microstat HiRes / HiRes2, fitted with 0.5mm thick ZnSe window.
Sample Holder Optical (Microstat) VH2 - An optical sample holder for use with a Microstat optical cryostat, with 12.5mm hole and clamp for transmission measurements.
Spares kit for Microstat OVC containing O rings & Screws. These kits are used to service and maintain your optical cryostat to ensure optimal performance.
Microstat HR2 Bottom Plate With Spec B 25mm Clear Access (QOVCB15HR2).Replacement bottom window plate for Microstat HiRes / HiRes2, fitted with 1.5mm thick Spec B window. This flange provides a clear diameter of 25mm to the sample region.
Spectrosil B Quartz Middle Window (Optistat CF/DN new style).A range of replacement fittings and accessories are available to help you change the optical configuration of your cryostat. The type of window material selected will be determined by the wavelenth and intensity of the radiation, the environmental temperature and whether or not beam polarisation is required.
Sample Holder Optical (Optistat 10mm clear) SH2+4. These sample holders are available for our range of 20 mm sample space liquid helium continuous-flow cryostats, nitrogen and helium bath cryostats.
Crystalline Quartz Inner Window (Optistat CF/DN new style).The Optistat CF / Optistat DN are both types of cryostat that provide superb optical access and an excellent cryogenic temperature environment for optical measurements.
Microstat HR2 Top Plate With Sapphire 25mm Clear Access (SOVC15HR2). Replacement top window plate for Microstat HiRes / HiRes2, fitted with 1.5mm thick Sapphire window.
Thermal Link for Optistat/Spectrostat. A range of replacement fittings and accessories are available to help you change the optical configuration of your cryostat.
Microstat HR2 Top Plate With Spec B 10mm Clear Access (QOVC05HR2). Replacement top window plate for Microstat HiRes / HiRes2, fitted with 0.5mm thick Spectrosil B window.
ESR Vacuum Quartz Tube (old style). Sample max OD: 5.0mm, OD vacuum quartz: 10.9 to 11.0mm, ID vacuum quartz: 7.0 to 7.1mm, Lower O-ring sealing section to cryostat: 19.0 to 19.1mm, Overall length: 315mm, Support quartz OD: 6.45mm, Support quartz ID:5.4mm
ESR Vacuum Quartz Tube (new style) - EQ1. Sample max OD: 4.5mm, OD vacuum quartz: 10mm, ID vacuum quartz: 6.51mm, Lower O-ring sealing section to cryostat: 19.0 to 19.1mm, Overall length: 315mm, Support quartz OD: 5.92mm, Support quartz ID:5.1mm
